Digital Coin-Op Shower Timer | US Quarter

Think of this US Quarter Digital Shower Timer like a smart parking meter that starts a countdown when you put in US quarters. It’s made from strong steel with a shiny white finish and polished chrome parts where you insert and return the coins. You can put in 1 to 16 quarters, and it will count down from 1 minute to almost 17 hours.

This digital coin operated timer has a screen that shows how much time is left and can hold about 300 quarters. The timer is very secure with a special key lock to keep the coins safe. It needs to stay dry, and an electrician has to set it up. You can easily adjust the settings with simple switches.

Table comparing coin-timer voltage to recommended solenoid voltage with notes on compatibility.

General Information

Timer Operation Type	US Quarters Digitial Coin Timer
Mounting	(3) #8 or #10 Screws
Construction Material	18 SWG Mild Steel
Finish	Scratch Resistant White Epoxy Polyester Powder Coated Paint; Coin Entry & Coin Return Cup are made of polished chrome

Connections & Dimensions

Height	9.75"
Width	5.50"
Depth	6"
Weight	7 lbs
Input Voltage	115 VAC, 24 VAC, and 230 VAC

Product Features

Working Temperature Range	-40 Degrees F - 104 Degrees F
Time Adjustable	Yes, 1 Minute - 999 Minutes
Humidity	95% Relative non-condensing
Cash Box	Holds Approximately 300 US Quarters
Number of Coins to Vend	1 to 16 (Adjustable via SwitchBank)
Three Digit Display	Shows the Minutes Count Down
Vandal Resistant	Key Lock for Extra Security
Body	Corrosion Resistant
CAUTION	Timer is NOT Waterproof. Do NOT Expose Timer to Direct Water Contact

What's Included

Item(s)	Shower Timer

What's Not Included?

Item(s)	Solenoid Valve Transformer: 115-12VDC1000 Ground Fault Circuit Breaker (GFCI) Electrician: Timer must be wired by a licensed electrician

Certifications & Approvals

Safety Listing(s)	UL Listed (UL file # E224248) ADA Compliant

Applications & Uses

Facility Types	Billiards / Pool Halls Campgrounds and RV Parks
Systems / Equipment	Air Compressors Air Conditioners Control Floodlights Coin-Operated Shower Timers Indoor and Outdoor Pool Showers Indoor and Outdoor Beach Showers
Markets	Commercial Laundromats Commercial and Residential

Documents

Installation Instructions	Coin Timer Download

Related Products

Product(s)	Solenoid Valves 1/2" \| Normally Closed
